Large Display Timer

Large Display Timer

Clocks and examination timers for schools, offices and colleges - let us know what you need [here] and we will send you all the information you need.

Example of a custom made outdoor large digit sport timer system we made for for Gravity Jet Suit racing...
A large digit countdown timer display which we designed, built and supplied to help publicise the launch of a new luxury bus service by Go North-East's premium interurban X-lines brand.
Large digital clocks are ideal in warehouses, so that everyone can see the time easily, from wherever they are. Sealed IP65 and suitable for indoor and outdoor mounting, cold stores, washdown etc.
The digital examination clock for our school arrived on Friday and has been used today for the first GCSE exam, we are really happy with it.

Carolyn W.

Example of a Fusion Series large digit timer, with 400mm high digits, suitable for viewing up to 200m away. Shown during functional testing in our Bedfordshire factory.
Here is the above large digit count down timer display, in use at an architectural launch of a new development project, counting down to completion.

Useful functions in our large display range...

:: 0-10V Large Displays
:: 4-20mA Large Displays
:: Clocks/Timers - Large digit
:: Counters - Large Digit
:: Custom Displays, Large digit
:: Down Timers - - Large digit
:: Factory Production displays
:: Health & Safety
:: Load Displays, Large digit
:: OEE Displays
:: Production Efficiency
:: Production Rate - Large digit
:: Production Performance
:: RPM Displays - Large digit
:: RS232/485 slave displays
:: T24 wireless data input
:: Takt Timers - Large digit
:: Temperature / Humidity
:: Time / Temperature
:: Weight / Weighbridge

These UK designed and built large LED displays let you clearly see important information from a distance. Time is a critical measurement, especially in a large factory or organisation, where many people need to arrive and leave at the same time.

New: Ex nR Atex clocks and timers

For hazardous areas we can offer the following explosion proof options on most clocks and timers. Tell us what you need and we will be pleased to quote for Atex certified systems
  • Zone 1 ii 2 G Ex px iiC T6/T5/T4 Gb *
  • Zone 2 ii 3 G Ex nR iiC T6/T5/T4 Gc **
  • EXD Zone 2 on request - POA

* - Requires pressurised air system
** - any product
The London Electronics ATEX certified clocks and timers are supplied certified for use in the condition in which they are supplied. No liability will be assumed for any loss or damages of any nature, direct or indirect, including any loss of profits or consequential damages, injury or death suffered or incurred by the buyer as a consequence of failure to install, use and/or apply the product within the scope of the installation document and certification supplied.

Exam timer digital clock and student information board for schools...
As well as time of day, our Fusion clock displays can be used as elapsed timers, either counting up from 0 or counting down from a preset time. These are ideal in Takt timing applications, process curing and as count-down displays to a big event. They are also ideal for showing factory safety data such as days since last accident, with automatic day counting and simple preset and reset functions.
An indoor clock with 400mm high digits being QA tested...
'We had a specific requirement for our station timers and London Electronics were not fazed by this at all.
James visited our site with demo models and explained very clearly what he needed from us in order to get the best product.
We had changing circumstances in our project and LE responded quickly to all. When faced with meeting a much earlier deadline than expected they really pushed on so we could get all the timers we needed.
Overall they are very professional company, the products they have supplied are top quality and I will be using them in any further projects.'
Paul Johnson, Maintenance Engineer: Bentley Motors Limited

Sports timing displays, custom made to suit specific needs.
This blue large digit timer has wireless connectivity to a manufacturing process and shows process Takt Time
'Hi Bob,
Here are some photos of the Displays and a short video in action.
Thanks for some good work by LEL, they are just what we wanted.'
Best Regards,
Denis Sturman
C&I Engineer
Saint Gobain Glass

With London Electronics displays, you have a wide choice of character heights for different viewing distances.
You should measure the maximum viewing distance you'll need, and use this chart to work out the ideal character size for you.
This will make sure you won't have to struggle to read the display. And, you won't pay too much for a display which is bigger than you need.
Download this viewing distance chart - click to download...

Cloud based clocks with alarms and messaging

We can also provide large cloud-based LCD clocks synchronised to network time, which can contain break time information, sound triggers, moving text messages etc.
We can provide clocks which are wireless-linked for synchronisation and include sounders to alert your team of breaks.
The schedule can be set up on a PC application we provide free of charge.
Please see example below. Click the software pane to download the software as a zipped file.
Factory Clock alarm / sounder scheduling software
This Windows software allows you to create a schedule of timed events, which can be tailored for each day. By including alarm relays in your clock, the clock can control sounders, lights, interlocks etc. Timing can be for a short duration of a few seconds, ideal for sounders, or can span hours.
You can have up to 4 alarm relay channels to control up to 4 individual devices, each with different timings.
Top features of our Large LED display Clocks:
  • Automatic Summer and Winter time correction
  • Can be free-running or synchronised
  • Can also be used as up or down timers
  • Sealed IP65 as standard for outdoor or food processing use.
  • Viewing distances available from 25m up to 160m
  • Wall, Suspension or panel mounting
  • 95-265V AC or 11-30V DC power supply
  • Alarm output relays, with scheduling software
  • Wide choice of display colours

Fusion 2 inch / 57mm 4 digit clock timer. Model F2-4C-H-0-0-0-R-AC-2-0
Fusion 2 inch / 57mm 6 digit clock timer. Model F2-6C-H-0-0-0-R-AC-2-0
Fusion 4 inch / 102mm 4 digit clock timer. Model F4-4C-H-0-0-0-R-AC-2-0
Count-down and count-up timers can accept Start/Stop/Reset inputs and can count up or down from a preset value.
Days since last accident display
Counting down to the Olympics with our Fusion large digit timer displays...
Counting down to big public events...
Game timing displays and sounders for outdoor competition...

  • Designed and built in England
  • Automatic summer/winter time correction
  • Precision HH:MM 12 or 24 hour format
  • Waterproof IP65 all round, glanded cable entries
  • 3 year warranty

LELCLK2: 25m viewing distance.
57mm digit factory clocks HH:MM
Saintealed IP65.
Indoor brightness.
Wall or Suspension mounting (specify your choice).
Model number:
F2-4C-H-0-0-0-R-AC-2-0 or
Power 95-265 V AC
291mm wide x 155mm high x 75mm f-b.

LELCLK4: 50m viewing distance.
102mm digit factory clocks HH:MM, sealed IP65.
Indoor brightness.
Wall or Suspension mounting (specify your choice).
Model number:
F4-4C-H-0-0-0-R-AC-2-0 or
Power 95-265 V AC
453mm wide x 196mm high x 75mm f-b.

LELCLK6: 75m viewing distance.
150mm digit factory clocks HH:MM, sealed IP65.
Indoor brightness.
Wall or Suspension mounting (specify your choice).
Model number:
F6-4C-H-0-0-0-R-AC-2-0 or
Power 95-265 V AC
580mm wide x 246mm high x 75mm f-b.

LELCLK8: 100m viewing distance.
200mm digit factory clocks HH:MM, sealed IP65.
Indoor brightness.
Wall or Suspension mounting (specify your choice).
Model number:
F8-4C-H-0-0-0-R-AC-2-0 or
Power 95-265 V AC
750mm wide x 290mm high x 75mm f-b.

LELCLK12: 150m viewing distance.
300mm digit factory clocks HH:MM, sealed IP65.
Indoor brightness.
Wall or Suspension mounting (specify your choice).
Model number:
F12-4C-H-0-0-0-R-AC-2-0 or
Power 95-265 V AC
1050mm wide x 408mm high x 75mm f-b.

LELCLK16: 200m viewing distance.
400mm digit factory clocks HH:MM, sealed IP65.
Indoor brightness.
Wall or Suspension mounting (specify your choice).
Model number:
F16-4C-H-0-0-0-R-AC-2-0 or
Power 95-265 V AC
1401mm wide x 515mm high x 75mm f-b.

Optional Power Cables
Our clocks are normally delivered without power cables, to allow your installers to cable them to a spur outlet.
If you need your clocks to be delivered with pre-installed power cable and moulded 13A plug, please choose one of these options:-
ULPLG3 = 3 metre length cable & moulded UK plug:

ULPLG5 = 5 metre length cable & moulded UK plug:

Branded with your logo and corporate colours for £75.
Branding on 12 inch displays is £105
Phone +44 01767 626444
Email [email protected]

See the technical manual at [info]
* No additional discount available.
This is the lowest nett price on these displays.

A custom count-down timer display...

Days since last accident displays...

Wall mounting brackets
Click to download engineering drawing...

Suspension mounting brackets
Click to download engineering drawing...

The wired Remote Programmer for the Fusion series, model RPFUSION, complete with 2m of cable and circular 5 pin connector.
